| Box Length (in): 25 5/16 |
| Box Width (in): 25 7/8 |
| Box Height (in): 6 5/8 |
| Box Weight (lbs): 18 |
| Core Length: 18 11/16 IN |
| Core Width: 20 11/16 IN |
| Core Thickness: 1 11/16 IN |
| Inlet Length (in): 20 3/4 |
| Inlet Width (in): 2 3/16 |
| Outlet Length (in): 20 3/4 |
| Outlet Width (in): 2 3/16 |
| Inlet Diameter: 1 3/8 Right IN |
| Outlet Diameter: 1 3/8 Left IN |
| No. Of Rows: 3 |
| Oil Cooler (in): 14 3/4 (high-effeciency Concentric Type) |
| Core Material: Copper |
| Tank Material: Brass |
| Down Flow Or Cross Flow Type: Down Flow |
| Radiator Cap Supplied: No |
| Csf Cap Number: 4502 |
| Hazardous Material: No |
| Tech Note: ALL METAL model. |
| CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road |
| OEM specified Copper-Brass Construction |
| Easy to recore & repair |
| No risk for coolant contamination and damage to sensitive seals, water pump & thermostat |
| OEM specified Single Piece - Deep Drawn Brass Tanks with Ribs for added Strength & Durability |
| Tubes - Special coated OEM specified Double Lock Seam Joints for Long Life |
| Fins (Heart of Radiator) - High Performance Multi-Louvered Design - OEM Spec |
| Side Channels - Coated Steel for Strength & Durability |
| Reinforced Inlet & Outlet Connections with Thru Pipe Design |
| 100% leak tested before leaving factory at 150% of operating pressure |
| Industry Best Packaging - 10 Foot Drop Test Standard |
| Drop-in Fit |
| Built for OEM Cooling - High Performance Transmission Cooler with special Built-in Turbulators |
| All components are installed, torqued & tested on Radiator during assembly |
