Fits the following 2016 Audi A3 Sportback e-tron applications:
- Audi A3 Sportback e-tron 1.4L L4
OE-style direct-fit Auxiliary Radiator (secondary intercooler).
NOTE: This is the AUXILIARY radiator (secondary cooler), not the main engine radiator. Used for intercooler cooling on the 1.4L turbo engine. O.E.M. style Plastic tank & Aluminum core with quick-connect inlet & outlet pipe.
| Product Attributes |
|---|
| Bottom Hose Fitting (In): 1 1/4 Left |
| Box Height (In): 5 1/4 |
| Box Length (In): 31 1/4 |
| Box Weight (lbs): 8 |
| Box Width (In): 20 |
| Core Length (In): 25 9/16 |
| Core Material: Aluminum |
| Core Thickness (In): 7/8 |
| Core Width (In): 17 |
| Cross-flow/ Down-flow: Cross Flow |
| Hazardous Material: No |
| Inlet Length (In): 17 7/16 |
| Inlet Width (In): 1 3/8 |
| No. of Rows: 1 |
| Oil Cooler (In): No |
| Outlet Length (In): 17 7/16 |
| Outlet Width (In): 1 3/8 |
| Radiator Cap Supplied: No |
| Tank Material: Plastic |
| Top Hose Fitting (In): 1 1/4 Left |
| Tech Note: O.E.M. style Plastic tank & Aluminum core with quick-connect inlet & outlet pipe. |
About CSF Radiators:
- CSF factories are ISO/TS-16949 certified
- OEM specified Plastic Tank — Aluminum Core Construction
- 100% leak tested before leaving factory at 150% of operating pressure
- Drop-in Fit
- High Performance Transmission Cooler with special Built-in Turbulator, when applicable
